High efficiency spray, the material usage ratio > 95%, Spray pattern uniformity +/- 2%

Maximum spray area coverage: 300mm × 300mm (SNR300), 500mm x 500mm (SNR500)

Precision Syringe Pump Liquid Dosing/Dispensing.

Full digital ultrasonic generator:

• Sonaer’s multi-DSPs closed loop control technology provides highly stable operation.
• Auto Atomization Power Adjustment (AAPA).
• Real time operating frequency display.
• VMD Simulation based on physical properties of the medium during atomisation.

SNR300 XYZ servo robot motion system [400mm(X) x 400mm(Y) x 100/200mm (Z)], maximum speed of 1000mm/s on X&Y axes.

SNR500 XYZ servo robot motion system [600mm(X) x 600mm(Y) x 100/200mm (Z)], maximum speed of 1000mm/s on X&Y axes.

Self-cleaning ultrasonic nozzle prevents clogging.

All system components are compatible with the typical solvents such as; THF, acetone, DMAC, toluene, chloroform, and polymers such as; urethanes, polycarbonates, silicones, styrene.

Exhaust system interface: ready for connecting to exhaust system of workshop or lab. HEPA filter facility.

Integrated control of the nozzle, liquid delivery, and motion system by full color touch panel with user friendly interface.

Built in PC and full color HMI with touch screen and keyboard.

SNR300 Dimensions (cm): 150 W x 90 D x 75 H, Weight: 150Kg (Note- Dimensions and weight may vary subject to the level of customization).

SNR500 Dimensions (cm): 160 W x 120 D x 175 H, Weight: 350Kg (Note- Dimensions and weight may vary subject to the level of customization).

Power input: 120-240VAC 50/60Hz, single phase, 16A.

Ethernet connection and Camera for remote process monitoring and record keeping or troubleshooting.

Laser targeting for coating position.
